mysql gtid replication step-by step | MySQL replication gtid vs binlog

GTIDs (Global Transaction Identifiers) have revolutionized MySQL replication, bringing transaction-based consistency and simplifying the overall management of replicated environments. With GTID replication, each transaction is uniquely identified and tracked across the entire replication topology. This eliminates the need to manually manage binlog file names and positions, a common source of errors and complexity in traditional binlog-based replication. This article provides a comprehensive, step-by-step guide to setting up MySQL GTID replication, covering various aspects from enabling GTID mode to advanced configurations like multi-master replication and integrating with tools like phpMyAdmin.

Why Use GTID Replication?

Before diving into the configuration, let's understand the key advantages of GTID replication over traditional binlog-based replication:

* Simplified Management: GTID replication eliminates the need to track binlog file names and positions manually. The replica automatically identifies and requests the necessary transactions from the source.

* Improved Consistency: GTIDs ensure that all transactions are applied exactly once on each replica, preventing data inconsistencies caused by skipped or duplicated transactions.

* Failover Automation: GTID replication simplifies failover procedures. A new source can be easily promoted, and replicas can automatically connect to the new source and resume replication from the correct point.

* Simplified Topology Changes: Adding or removing replicas in a GTID-based replication topology is much easier than in a binlog-based setup.

* Scalability: GTID replication simplifies the management of large and complex replication topologies, making it easier to scale your MySQL infrastructure.

Categories Covered:

This article covers the following key areas:

* Enabling GTID mode in MySQL

* MySQL GTID replication step-by-step

* MySQL replication GTID vs binlog

* Enabling GTID in MySQL

* MySQL master-slave replication setup with GTID

* MySQL workbench replication with GTID

* MySQL multi-master replication setup with GTID

* phpMyAdmin replication with GTID (brief overview)

1. Enabling GTID Mode in MySQL

Enabling GTID mode is the first step in setting up GTID replication. This needs to be done on both the source (master) and replica (slave) servers. Important: Before enabling GTID, ensure you have a recent backup of your databases, as this process requires a server restart and could potentially lead to data loss if not handled carefully.

Steps:

1. Stop the MySQL Server: Use the appropriate command for your operating system to stop the MySQL server. For example, on Linux systems using systemd:

```bash

sudo systemctl stop mysql

```

2. Edit the MySQL Configuration File (my.cnf or my.ini): Locate the MySQL configuration file. Common locations include `/etc/mysql/my.cnf`, `/etc/my.cnf`, or `C:\ProgramData\MySQL\MySQL Server X.X\my.ini` on Windows. Add the following lines to the `[mysqld]` section:

```ini

[mysqld]

gtid_mode=ON

enforce_gtid_consistency=ON

log_slave_updates=ON

server_id= # Replace with a unique integer for each server in the replication topology. Crucial for identifying each server.

log_bin=mysql-bin # Enable binary logging

binlog_format=ROW # Row-based logging is generally recommended for GTID replication

relay_log=mysql-relay-bin # Enable relay logging on replicas

# The following settings are highly recommended for production environments

transaction_write_set_extraction=XXHASH64

binlog_transaction_dependency_tracking=WRITESET

slave_preserve_commit_order=ON

```

Explanation of Configuration Parameters:

* `gtid_mode=ON`: Enables GTID mode. You can also transition GTID mode in stages using `gtid_mode=ON_PERMISSIVE` which allows both GTID and non-GTID transactions during the transition.

* `enforce_gtid_consistency=ON`: Ensures that only GTID-safe statements are allowed. This prevents data inconsistencies.

* `log_slave_updates=ON`: Replicas should also log updates they receive from the source to their own binary logs. This is crucial for multi-tier replication topologies or when promoting a replica to be a source.

* `server_id= `: A unique integer identifying each server in the replication topology. This is essential for GTID replication to function correctly. Choose a different number for each server.mysql gtid replication step-by step

* `log_bin=mysql-bin`: Enables binary logging, which is required for GTID replication.

* `binlog_format=ROW`: Sets the binary logging format to ROW. While STATEMENT is possible, ROW is generally recommended for its greater reliability and accuracy, especially when dealing with complex data types or stored procedures.
